Characteristics
QON
QON is a modular lighting system designed for versatile architectural applications.
Developed around a balanced approach to performance, efficiency, and installation practicality, the system is suited for scalable commercial and spatial environments.
Its integrated modular architecture combines optics, structure, and thermal management within a refined compact form, delivering stable and efficient lighting performance.
A 42° cut-off angle provides effective glare control and visual comfort for everyday spatial applications.
With a simplified structural design and efficient installation logic, the system supports reliable performance with optimized application efficiency.
Parameters
| Model | 071075 |
| Power | 9W / 10W / 12W |
| Cut-out | Ø75mm |
| Installation | Trim / Trimless |
| Finish | BK / WH |
| Beam Angle | 15° / 24° / 36° / 50° |
| CCT | 2700K / 3000K / 3500K / 4000K |
| CRI | Ra90 / Ra97 |
| Visual Comfort | Low Glare Design |
| MacAdam | SDCM＜3 |
| Dimming | ON/OFF / DALI / 0-10V / PWM |
| IP Rating | IP20 / IP54 |
| Lifetime | 50000h |
| Material | Aluminium |
